Operio Mobile US

Mobile air zone unit

The innovative Operio Mobile unit ensures that both the surgical site and instruments near the surgical site are protected from airborne contaminants during entire surgical procedure.

Operio Mobile is a clean airzone unit, withanintegrated detachable instrument tray, to be used in the operating zone, which produces a directed, non-turbulent ultra-clean air flow to the surgical site during ophthalmic surgery and to the sterile instruments used during surgery.

The ultraclean airflow is easily aimed over the surgical siteor any other area where thereis a need tokeep the sterile integrity intact.

Operio Mobile has a unique protective barrier in order for the unit to be placedclose to the ORtable. The unit circulatestheambient air through a HEPA filtration system, cleaning the air, which prevents dangerous, airborne bacteria-carryingparticles fromcoming intocontact with the surgical site, as well as surgical instruments near the surgical site.

The unit is easy to use andtransport between operation rooms and/or preparation rooms.

  • Operio Mobile is easy to set up requiring no changes to the room



  • Operio Mobile can be used instead of an instrument table near the surgical site next to the patient, saving valuable space.



  • Operio Mobile guarantees < 5 cfu/m3 air inside the clean air zone.



Compliance:

FDA 510(k) cleared for US market

Toul Meditech’s Quality Management System is conforming to the requirements of ISO 13485:2012.

Operio Mobile conforms to UL Std. 61010-1 and is certified to CAN/CSA Std. C22.2 No 61010-1.



Physical Data:

Air Zone Unit

Overall size: 24”L x18”Wx51-67”H
Weight: 92 lbs

Tray:

Tray size:

18”x 24” (optional 16” x 18”)

Loadlimitation:Tray may be loaded with max11 lbs

Min-max height adjustment: 31” – 47”


Power Data:

Power Supply:

120 VAC, 60 Hz

Power consumption:

290 VA (23 VA in standby-mode)


Air Flow Data:

Velocity:

0.4 – 0.5 m/s, 400 m3/h


HEPA filter:  H14 Filter, High Efficiency Particles Filter
